ENSONIQ DP/4+ User Manual

Section 3 — Config Parameters
10 ENSONIQ DP/4+ Reference Manual
2 Source Config
o0
2 Source Config
1,2 >AB 3,4 >CD
00 — 2 Source Config
The 2 Source Config divides the DP/4+ into 2 multi-effects processors, each containing 2 units of
processing power.
o1
AB Input Select=
(1,2) Stereo
01 — AB Input Select Range: (1,2) Stereo or (1) Mono
This parameter selects either a mono or stereo input for Units A and B.
o2
CD Input Select=
(3,4) Stereo
02 — CD Input Select Range: (3,4) Stereo or (3) Mono
This parameter selects either a mono or stereo input for Units C and D.
o3
AB Unit Routing=
[A+B] parallel
03 — AB Unit Routing Range: serial, parallel, feedback1, or feedback2
Units A and B can be routed together in either serial, parallel, or two different kinds of feedback
(explained in the 1 Source Config description).
