ENSONIQ DP/4+ User Manual

Section 3 — Config Parameters
ENSONIQ DP/4+ Reference Manual 11
o4
CD Unit Routing=
[C+D] parallel
04 — CD Unit Routing Range: serial, parallel, feedback1, or feedback2
Units A and B can be routed together in either serial, parallel, or two different kinds of feedback
(explained in the 1 Source Config description).
o5
Dry Path Around
AB Amt =00
05 — AB (Config Dependent)
06 — CD (Config Dependent)
For a complete discussion of config dependent parameters, please refer to 1 Source Config
parameters 05 and 06 earlier in this section.
o7
(b)ypass (k)ill
A=b B=b C=b D=b
07 — Bypass Kill (Unit) A 09 — Bypass Kill (Unit) C
08 — Bypass Kill (Unit) B 10 — Bypass Kill (Unit) D
These parameters determine what happens when you bypass a unit (the red LED is lit). When set
to bypass (b), only the dry signal passes through the unit. When set to kill (k), no signal passes
through the unit.
Note: In order to use a foot switch to bypass a unit, it must be set to function as a
DP/4+ controller (see the description of System•MIDI parameters 45 to 48 in Section 4
— System•MIDI).
