Section 2 — Algorithms
102 ENSONIQ DP/4+ Reference Manual
01 — Mix
02 — Volume
See the descriptions under the Mix and Volume Parameters, in the beginning of this section. For
this algorithm, we recommend a mix setting of 99.
03 — Vocal Pos Range: -127 to +127
This is used to compensate for panning in the original recorded vocal.
04 — L/R Delay Range: -127 to +127
This makes up for any slight delay that may exist between the left and right channels due to
idiosyncrasies of the recording or playback process.
05 — Bass Level Range: 00 to 99
Controls the output level of the lowpass filters. This signal goes directly to the main outputs.
06 — Treble Level Range: 00 to 99
Controls the output level of the highpass filters. This signal goes directly to the main outputs.
07 — Mid Level Range: 00 to 99
Controls the output level of the bandpass filters. As shown in the diagram, the output of the
bandpass filters goes to the cancellation circuit.
08 — Bass Fc Range: 80 to 1000 Hz
Determines the cutoff frequency of the lowpass filters. If this parameter is set too high, some
vocal components may begin to leak into the output of the effect.
09 — Trebl Fc Range: 1000 to 16000 Hz
Determines the cutoff frequency of the highpass filters. If this parameter is set too low, some
vocal components may begin to leak into the output of the effect.
10 — Mid Fc Range: 80 to 16000 Hz
Determines the cutoff frequency of the bandpass filters.
11 — BW Range: 80 to 16000 Hz
This determines the bandwidth of the bandpass filters.
12 — Mod1 Source 16 — Mod2 Source
13 — Mod1 Destination 17 — Mod2 Destination
14 — Mod1 Param Range Min 18 — Mod2 Param Range Min
15 — Mod1 Param Range Max19 — Mod2 Param Range Max
See the descriptions under the Algorithm Modulators earlier in this section.
