ENSONIQ DP/4+ User Manual

Section 3 — Config Parameters
ENSONIQ DP/4+ Reference Manual 13
o4
AB Output Select
A>1 B>2 DualMono
04 — AB Output Select Range: Dual Mono or Mixed Stereo
This parameter allows you to assign Units A and B as two independent mono signals to Outputs
1 and 2 respectively, or mix Units A and B into a stereo output.
o5
(b)ypass (k)ill
A=b B=b C=b D=b
05 — Bypass Kill (Unit) A 07 — Bypass Kill (Unit) C
06 — Bypass Kill (Unit) B 08 — Bypass Kill (Unit) D
These parameters determine what happens when you bypass a unit (the red LED is lit). When set
to bypass (b), only the dry signal passes through the unit. When set to kill (k), no signal passes
through the unit.
Note: In order to use a foot switch to bypass a unit, it must be set to function as a
DP/4+ controller (see the description of System•MIDI parameters 45 to 48 in Section 4
— System•MIDI).
