Section 2 — Algorithms
ENSONIQ DP/4+ Reference Manual 73
06 — PitchShifter Vc 1 Pan Range: -99 to +99
Allows you to assign the location of output Voice 1 in the stereo field. A value of -99 would be
far left, and +99 would be far right.
07 — PitchShifter Vc 2 Semi Range: -12 to +12
Adjusts the pitch of Voice 2 up to an octave above or below the original pitch in semi-tones.
08 — PitchShifter Vc 2 Fine Range: -99 to +99
This parameter allows you to fine tune the pitch of Voice 2.
09 — PitchShifter Vc 2 Level Range: 00 to 99
Adjusts the volume of Voice 2. A setting of 00 would eliminate any audible pitch shift.
10 — PitchShifter Vc 2 Pan Range: -99 to +99
Allows you to assign the location of output Voice 2 in the stereo field. A value of -99 would be
far left, and +99 would be far right.
11 — PitchShifter LFO Rate Range: 00 to 99
This parameter controls the rate of pitch modulation which creates a chorusing effect. To achieve
chorusing, this rate must be very low.
12 — PitchShifter LFO Width Range: 00 to 99
This parameter controls the excursion of pitch modulation. Since the rate is usually very low,
then the width is usually very large.
Mod1 Source Mod2 Source
Mod1 Destination Mod2 Destination
Mod1 Param Range Min Mod2 Param Range Min
Mod1 Param Range Max Mod2 Param Range Max
See the descriptions under the Algorithm Modulators earlier in this section.
