Section 2 — Algorithms
ENSONIQ DP/4+ Reference Manual 75
08 — PitchShift Vc 2 Fine Range: -99 to +99
Allows you to fine tune the pitch of Voice 2. Slight shifts create something like a chorused effect.
09 — PitchShift Vc 2 Level Range: 00 to 99
This parameter adjusts the volume of Voice 2.
10 — PitchShifter Vc 2 Pan Range: -99 to +99
Allows you to assign the location of Voice 2 in the stereo field. A value of -99 would be far left,
and +99 would be far right. This is actually a balance control which determines how much of the
left and right inputs will be fed to Vc2.
11 — PitchShift Dry Level to DDL Range: 00 to 99
Lets you bypass the pitch shifter with an internal dry signal, and send it through the digital
delay. Higher values would send more of the dry signal to the delay. The purpose of this
parameter is to mix the dry signal appropriately with the pitch shifted delay signals.
12 — PitchShift Left Delay Time Range: 0 to 1500 ms
Controls the amount of time for the pitch shifted signal to delay from the left input.
13 — PitchShift Right Delay Time Range: 0 to 1500 ms
Controls the amount of time for the pitch shifted signal to delay from the right input.
14 — PitchShift Delay Mix Range: 00 to 99
Controls the mix between the delay signal and the pitch shifted signal. A setting of 00 would be
all pitch shifter, and no delay. A setting of 99 will be all delay and no direct pitch shift.
15 — PitchShift Delay Regen Range: -99 to +99
Controls the amount of feedback from the output of the delay back into the input of the pitch
shifter. This allows you to create special effects with ascending/descending delays.
16 — Mod1 Source 20 — Mod2 Source
17 — Mod1 Destination 21 — Mod2 Destination
18 — Mod1 Param Range Min 22 — Mod2 Param Range Min
19 — Mod1 Param Range Max23 — Mod2 Param Range Max
See the descriptions under the Algorithm Modulators earlier in this section.
