Enterasys SecureStack C2 C2G170-24 Hardware Installation Guide

Overview
1-2 Introduction
C2G170-24
TheC2G170‐24(Figure 1‐1)hasseveraltypesoffrontpanelportandrearpanel
connections,whichinclude:
•TwentyfourSFPportsthatsupport
– optionalMini‐GBIC1000BASE‐TEthernetovercopperinterfaceconnectionsfor
10/100/1000Bpsoperation
– optional1000BASE‐SX/‐LX/‐ELXfiber‐opticconnections
•Rearpanelconnectorsforhigh‐
speedconnectionsinastackconfiguration.
•RearpanelRedundantPowerSupply connectorforaredundantpowersupply
connection.TheswitchconnectstoanEnterasysC2RPS‐SYSusingaC2RPS‐PSM
Cable.
Figure 1-1 C2G170-24 Stackable Switch
Caution: The C2G170-24 is not a PoE-compliant device. Do not connect a SecureStack
C2 PoE Redundant Power System (C2RPS-POE) to the power connector. Otherwise,
damage to the device may result.
Precaución: El dispositivo C2G170-24 no cumple con el estándar PoE. No conecte una
fuente de poder redundante (RPS) SecureStack C2 PoE (C2RPS-POE) al cable de
corriente directa. De lo contrario, el dispositivo puede dañarse.
1 DB9 RS232 console port connector 5 Two ports for stack connections
2 Status LEDs 6 Password Reset switch
3 Twenty-four SFP port slots for 1000 Mbps
Ethernet
7 AC power input connector
4 SFP port slot status LEDS 8 Connection for a C2RPS-SYS
Redundant power supply
Console
121110987654321
1
2
13
14
11
12
23
24
C2G170-24
CPU
UP
RPS
MGR
DOWN
242322212019181716151413
Redundant Power Supply
DC LINE 12V /13A MAX.
AC LINE
100-240 VAC
50-60 Hz
1.2 A MAX
MAC ADDRESS SERIAL NO.
STACK UP STACK DOWN
Ã
Ç
Back
Front
À Á Â
Ä Å Æ
