Installing the Switch on a Flat Surface
3-8 Hardware Installation
4. Removetheprotectivestripfromthebackofonerubberfootandpositionitona
markedlocationandpressfirmlyintoplace.Repeatthisproceduretoinstallthe
remainingthreerubberfeetintheotherthreelocations.
5. Afterinstallingtherubberfeet,returntheswitchtoitsuprightposition.
6. Proceedto
“GuidelinesforInstallation”onpage 3‐8.Forarackmountinstallation,
proceedto“RackMoun ting theSwitch”onpage 3‐9.
Guidelines for Installation
Locatetheswitchwithin152cm(5ft)ofitspowersourceandonasurfaceasshownin
Figure 3‐5.Ifanoptionalredundantpowersystemisgoingtobeinstalledandconnected
tothe14‐pinRedundantPowerSupplyinputconnectorontherearoftheswitch,
referto
theinstallationguideshippedwiththeredundantpowersystem.
Thenextsteptoinstalltheswitchisdependentonthetypeofinstallation.Ifinstalling
severalswitchesinastack,proceedto“ConnectingHigh‐SpeedStackingCables”on
page 3 ‐11.Ifinstallingtheswitchasastandalonedevice,
proceedto“ConnectingACand
RPSPower”onpage 3‐15forpowerconnectioninstructions.
Note: If a number of switches are being installed in a stack, repeat steps 1 through 4 to
install the rubber feet on each switch before continuing with the installation.
Caution: To ensure proper ventilation and prevent overheating, leave a minimum
clearance space of 5.1 cm (2.0 in) at the left, right, and rear of the switch.
Do not connect the switch to the AC power source until instructed to do so later in the
installation process.
Precaución: Para asegurar una buena ventilación y evitar que el sistema se
sobrecaliente, deje un espacio mínimo de 5.1 cm (2 pulgadas) con respecto a los lados y
a la parte posterior del aparato
No conecte la fuente del poder a la fuente primaria hasta que no se le indique..
