Mini-GBIC Input/Output Specifications
A-2 Specifications
Mini-GBIC Input/Output Specifications
TheMini‐GigabitEthernetCard(Mini‐GBIC)portinterfaceslotscansupport1‐Gbps
fiber‐opticandcopperconnectionsasdescribedinTable A‐2.TheoptionalMini‐GBICs
arehotswappable.
Processors/Memory
Processor MPC8245, 400 MHz processor
Dynamic Random Access
Memory (DRAM)
256 MB
FLASH Memory 32 MB
Physical
Dimensions 4.4 H x 44.1 W x 36.85 D (cm)
1.7 H x 17.4 W x 14.5 D (in)
Approximate Weight Gross: 6.57 kg (14.45 lb) (shipping carton containing one module)
Net: 5.32 kg (11.70 lb) (one module without packaging)
Predicted hours for Mean
Time Between Failures
(MTBF)
156,424 hours
Heat Dissipation (maximum) @ 51.75 W, 176.57 BTU/hr
Environmental
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity 5% to 90% (non-condensing)
Table A-1 Switch Specifications (continued)
Item Specification
Table A-2 Mini-GBIC Input/Output Port Specifications
Item Specification
MGBIC-LC01 Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC connector.
MGBIC-LC03 Provides one LC fiber-optic multimode port that is compliant with the
1000BASE-SX standard LC duplex style connector.
MGBIC-LC09 Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-LX standard LC connector.
