Console Port Pinout Assignments
A-6 Specifications
Console Port Pinout Assignments
TheConsoleportisaDB9serialcommunicationsportforlocalaccesstoLocal
Management.RefertoFigure A‐1fortheConsoleportpinassignments.
Figure A-1 Console Port Pinout Assignments
Regulatory Compliance
TheC2G170‐24meetsthesafetyandelectromagneticcompatibility(EMC)requirements
listedinTable A‐12:
Data Rate 1 Gbps, IEEE 802.3:2000 compatible
1000BASE-T operation only
Automatic crossover detection
TX Output impedance 100 ohms, typical at all frequencies between 1 MHz and
125 MHz
RX Input impedance 100 ohms, typical at all frequencies between 1 MHz and
125 Hz
Table A-11 MGBIC-02 / Specifications (continued)
Item Specification
1 Pin 2, Received Data (input) 3 Pin 5, Signal Ground
2 Pin 3, Transmitted Data (output) All other pins not connected.
Â
À
Á
5
1
9
6
Table A-12 Compliance Standards
Regulatory Compliance Standards
Safety UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950,
and IEC 60950. The Mini-GBICs support laser connections
that meet the EN 60825 and 21 CFR 1040.10 standards.
Electromagnetic Compatibility
(EMC)
47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC,
EN 55022, EN 61000-3-2, EN 61000-3-3, EN 55024,
AS/NZS CISPR 22, and VCCI V-3.
