100BASE-TX Network
2-2 Network Requirements
100BASE-TX Network
Whenconnectinga100BASE‐TXsegmenttoaMGBIC‐02 RJ45port, useCategory5UTP
cabling.TheswitchattheotherendofthetwistedpairsegmentmustmeetIEEE802.3‐
2002100BASE‐TXFastEthernetnetworkrequirementsfortheswi tchestooperateat
100 Mbps.
1000BASE-T Network
TheMGBIC‐02enableyoutomakeRJ45copper1000BASE‐Tcompliantconnections.
Whenconnectinga1000BASE‐TsegmenttoanMGBIC‐02RJ45connector,useCategory5
UTPcablingorbetter(Cat egory5eisrecommendedfornewcableinstallations).The
deviceattheotherendofthetwistedpairsegment
mustmeetIEEE802.3‐2002
1000BASE‐TGigabitEthernetnetworkrequirementsforthedevicestooperateat
10/100/1000 Mbps.
1000BASE-FX Network
TheMini‐GBICportsocketsontheC2G170‐24enableyoutovarythetypeof1‐Gbpsport
connection.ThedeviceattheotherendsegmentmustmeetthesameGigabitEthernet
requirementsfortheconnecteddevicestooperateat1‐Gigabitspeed.Atthetimeof
printing,therewere
fiveMini‐GBICsavailablethatsupportfiber‐opticconnections,as
listedbelow:
•MGBIC‐LC01fora1000BASE‐SXcompliantLCfiber‐opticmultimodeconnection
•MGBIC‐LC03fora1000BASE‐SXstandardLCduplexstyleconnectormultimode
connection
•MGBIC‐LC09fora1000BASE‐LXcompliantLCfiber‐opticsingle‐modeconnection
•MGBIC‐MT01
fora1000BASE‐SXcompliantMT‐RJfiber‐opticsingle‐mode
connection
•MGBIC‐08fora10 00BASE‐ELXcompliantLCfiber‐opticsingle‐modeconnection
Note: When using the fixed ports on the switch for 100 Mbps operation use Category 5
UTP cabling with an impedance between 85 and 111 ohms for 100 Mbps operation.
The MGBIC-02 is capable of operating at 10, 100, or 1000 Mbps. This is accomplished by
the switch when Auto-Negotiation is enabled. This enables the switch to automatically
sense the transmission speed of the other device and adjust for the speed accordingly.
