Connecting AC and RPS Power
3-16 Hardware Installation
Figure 3-9 AC and PRS Power Connections
4. ObservethepowerCPULED(notshown)locatedonthefrontpanel.Duringthe
initialization,theCPULEDwillstartbyilluminatingsolidamber,thenstartblinking
green,thenblinkingamber,thenblinkinggreenagainuntiltheendofthe
initialization,andthenturnssolidgreen.
Iftheswitchis
astandaloneswitch,itwilltakeapproximately30 secondsforthe
switchtostartup.IftheswitchisastackManager,itcantakeupto3minutesormore
tostartup,dependingonthenumberofMemberswitchesinthestack.
RPS Power
Ifyouareinstallinganoptionalredundantpowersystem(C2RPS‐SYS),refertothe
installationinstructionssuppliedwiththeRPS.TheswitchisconnectedtoaC2RPS‐PSM
usingaC2RPS‐PSMCable.
1 AC power cord 2 AC power connector 3 Connector for external redundant power supply
Note: If the CPU LED illuminates solid red, there was a critical failure. For more
information about the LED indications and troubleshooting, refer to Chapter 4. If you need
additional help, contact Enterasys Networks. Refer to “Getting Help” on page 1-5 for
details
.
