EPSON AcuLaser C9200N Revision D
PRODUCT DESCRIPTION Product Specifications 14
Confidential
Figure 1-3. Inside the printer
Table 1-3. Part Names
No. Name No. Name No. Name
1 Toner Cartridge (Yellow) 6 Photoconductor unit (Black) 11 Power switch
2 Toner Cartridge (Magenta) 7 Photoconductor unit (Cyan) 12 Cover H
3 Toner Cartridge (Cyan) 8 Photoconductor unit (Magenta) 13 Paper path G
4 Toner Cartridge (Black) 9 Photoconductor unit (Yellow)
5 Exposure window cleaning bar 10 Waste toner collector
5
11
4
3
2
1
10
6
9
7
8
12
13
