EPSON AcuLaser C9200N Revision D
PRODUCT DESCRIPTION Product Specifications 15
Confidential
DIMENSIONS AND WEIGHT
The following figure shows the dimensions and weight of the printer.
NOTE 1 : Manufacturing tolerance is ±5 mm in dimensions and ±0.5 kg in weight.
2 : Consumables are not included in the weight of the main unit.
Figure 1-4. Main Unit
Figure 1-5. Main Unit with Optional Units Installed
608 mm648 mm
477 mm
Main Unit 49.5 kg
629 mm699 mm
937 mm
Optional Cassette 14.8 kg
Main Unit + Optional Cassette 1 level 64.3 kg
2 levels 79.1 kg
3 levels 93.9 kg
Main Unit + Duplex Unit 52.8 kg
Main Unit + Optional Cassettes (3 levels) + Printer stand 102.4 kg
849 mm 725 mm 601 mm 477 mm
