EPSON AcuLaser C9200N Revision D
OPERATING PRINCIPLES Operating Principle of Main Unit Mechanism 47
Confidential
2.2.7.2 Drive
Figure 2-20. Drive overview
2.2.7.3 Operation
DEVELOPING DRIVE CONTROL
Figure 2-21. Developing Drive control
Developing Clutch/K (CL4)
PC Drum/K
Color PC Drum
Motor (M2)
PC Drum/Y
Color Developing
Motor (M3)
Developing
Roller
Supply/Agitating/
Conveying Screws
Toner Collecting Screw
Main Motor (M1)
4038T2C025AA
Main Motor (M1)
Color PC Drum Motor (M2)
Drum Charge Corona Bias/Y, M, C
Drum Charge Corona Bias/K
Color Developing Motor (M3)
Developing Clutch/K (CL4)
1st Image Transfer Pressure/
Retraction Clutch (CL3)
2nd Image Transfer Pressure/
Retraction Motor (M5)
Developing Bias/K (DC)
Developing Bias/Y, M, C (DC)
Developing Bias/K (AC)
Developing Bias/Y, M, C (AC)
