Epson EB-W06 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 12 Revision A
1.2 Specifications
 EB-E01/X06/W06/E10/X51/W51/W52
Model
EB-E01 EB-X06 EB-W06 EB-E10 EB-X51 EB-W51 EB-W52
Item
Specific
ation
of main
part
LCD
Size
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.55 inch
(C2fine)
0.55 inch
(C2fine)
0.59 inch
(C2fine)
0.59 inch
(C2fine)
Pixel number
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
786,432 pixels
(1024 x 768) x 3
786,432 pixels
(1024 x 768) x 3
1,024,000 pixels
(1280 x 800) x 3
1,024,000 pixels
(1280 x 800) x 3
Native resolution XGA XGA WXGA XGA XGA WXGA WXGA
Aspect ratio 4:3 4:3 16:10 4:3 4:3 16:10 16:10
Projection Lens
Focus Type Manual
Zoom
Type Digital Manual Manual Digital Manual Manual Manual
Ratio 1-1.35 1-1.2 1-1.2 1-1.35 1-1.2 1-1.2 1-1.2
Lamp
Type UHE
Power consumption 210W
Life
Normal 6,000 hours
Eco 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,300lm 3,600lm 3,700lm 3,600lm 3,800lm 4,000lm 4,000lm
Eco mode
Color mode: Dynamic,
Zoom: Wide
2,200lm 2,400lm 2,400lm 2,200lm 2,500lm 2,600lm 2,600lm
Sound output Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding)
RCA — 1 (Yellow) 1 (Yellow) — 1 (Yellow) 1 (Yellow) 1 (Yellow)
Digital HDMI 1
Video output Analog D-sub 15pin —
Audio
Input
RCA (L/R)—11—111
Stereo mini —
Output Stereo mini —
Mic Input Stereo mini —

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
