Epson EB-W06 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 166 Revision A
3.9 Part Names List
Part names are written as abbreviations in this manual. Below is the
correspondence table of the abbreviations and SPI notation of the part names.
PART NAMES LIST
Name used in this manual SPI Parts Name
Optical Engine Assy
OPT ENGINE ASSY-X;H971;PH;AS
OPT ENGINE ASSY-X;H972;PH;AS
OPT ENGINE ASSY-X;H975;PH;AS
OPT ENGINE ASSY-X;H976;PH;AS
OPT ENGINE ASSY-X;H981;PH;AS
OPT ENGINE ASSY-X;H982;PH;AS
OPT ENGINE ASSY-X;HA03;PH;AS
OPT ENGINE ASSY-X;H986;PH;AS
OPT ENGINE ASSY-WX;H973;PH;AS
OPT ENGINE ASSY-WX;H983;PH;AS
OPT ENGINE ASSY-WX;H987;PH;AS
OPT ENGINE ASSY-FH;H974;PH;AS
OPT ENGINE ASSY-FH;H978;PH;AS
OPT ENGINE ASSY-FH;H979;PH;AS
OPT ENGINE ASSY-FH;H980;PH;AS
Lamp Assy LAMP ASSY;H950;AS
Lower Case
CASE UNIT,LOWER;K1-WH;PH
CASE UNIT,LOWER;K1-BK;PH
CASE UNIT,LOWER;D1-WH;PH
CASE UNIT,LOWER;D1-BK;PH
RC Filter FILTER,RC
Front Foot FOOT UNIT,FRONT
Rear Foot FOOT,REAR,AS_CKD
Lower Shield Plate A SHIELD PLATE,LOWER;A;PH
Lower Shield Plate B SHIELD PLATE,LOWER;B;PH
FB Insulation Sheet SHEET,INSULATION,FB;H838;PH
Filter Board FILTER BOARD UNIT;H838;PI;2
Inlet Cable CABLE,INLET-H838;PH
IR Board PCB ASSY;H980IR-MP;PH
RCF Cable CABLE,RC FRONT-H850;PH;2
PS Holder HOLDER,PS
Lower Cushion Seal CUSHION,SEAL,LOWER;H850;PH
Lower Cushion CUSHION,LOWER;H850;PH
Inlet Fasten Plate
PLATE,FASTEN,INLET;KH;PH
PLATE,FASTEN,INLET;V16H;PH
INT Duct A
DUCT,INTAKE;A;K;PH
DUCT,INTAKE;A;D;PH
INT Duct B
DUCT,INTAKE;B;K;2;PH
DUCT,INTAKE;B,H978;PH
DUCT,INTAKE;B,H980;PH
INT Fan FAN;SR7039-THT-H838
Cable Fasten Tape TAPE,CABLE FASTEN;PH
INT Duct Cushion Seal C CUSHION,SEAL,DUCT INTAKE;C-H850;PH
INT Duct Cushion Seal D CUSHION,SEAL,DUCT INTAKE;D-H850;PH
TH Board PCB ASSY;H980TH-MP;PH
TH Cable H550 CABLE,TH-H550;PH;2
TH Cable H309 CABLE,TH-H309;PH;2
P4combo Module P4combo module;MP
FFC 15P FFC,SHIELD,15-H978
Lower Conduction Plate
PLATE,CONDUCTION,LOWER;K;2;PH
PLATE,CONDUCTION,LOWER;V;PH
Conduction Cushion CUSHION,CONDUCTION;PH
PS Ballast Assy PS BALLAST UNIT ASSY;H838;EP;PH2;5
Cable PS-MA CABLE,PS-MA-H838-B;PH;2
Cable PS-FB CABLE,PS-FB-H838;PH
Cable BA-Lamp CABLE,BA-LAMP-H838
PS Shield Plate
SHILED PLATE,PS;A;PH
SHIELD PLATE,PS;B;PH
Name used in this manual SPI Parts Name

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
