Epson EB-W06 Service Manual

EB-E01 series Troubleshooting INTERNAL USE ONLY
SEIKO EPSON 33 Revision A
2.1 Required Tools
The following tools are required in order to carry out troubleshooting of this
projector.
*1: When repairing a wide panel (16:10) model, prepare the video source and devices
considering the full screen display of 16:10 aspect.
*2: q.s.: Sufficient quantity
Name Qt. Application/Other
Projection screen 1 To project images on.
Genuine power cable 1
Genuine remote controller 1
Host computer 1 To output audio and video data to the projector*
1
(To check the component video input)
To control service tools
PC cable 1
Video equipment 1
To output audio and video data to the projector*
1
(To check the HDMI and composite video input)
Audio and Video cables
(HDMI/Composite/USB, and
each audio)
1 each
Multi tester 1
To measure resistance values and voltages (AC/
DC).
Double-sided tape q.s.*
2
To secure parts
General tools 1 set Tools given in " 3.1.4 Tools (p66)".
RS-232C cable 1 For writing DR data
USB memory or USB cable 1 For USB Updater
IPS tool 1
See " 3.5.10 Service tool list (p150)".
CAT 1
Intra-mart 1
RESCUE 1
USB firmware for updater 1
EasyMP Network firmware for
updater
1
Microsoft .Net Framework 3.5
or later
1
USB COM Driver 1

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
