EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 80 Revision A
3.3.6 Upper Case (Assy)
DISASSEMBLY PROCEDURE
 EB-E01/X06/W06/FH06/E10/X51/W51/W52/E20/X49/W49/118,
PL 119W, EH-TW740/TW750
1. See Flowchart (p70) and remove all parts up to the component below from
the projector.
Rear Case (p77)
2. Remove the six screws ( ) on the bottom.
Screws
C.B.P-TITE SCREW,2.5X10,F/ZN-3C
