Epson EB-W06 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 152 Revision A
3.6 Writing the DR Data
3.6.1 Overview
In this case (a new combination of them), you will write the DR data adjusted for the characteristics of the Optical Engine (current or replaced) into the newly-
combined MA Board according to the specified procedure. This section describes the specific repair process including how to write the DR data.
Conceptual diagram of the replacement using DR data
)DFWRU\
$63
6DOHV&RPSDQ\5HSDLUFHQWHU
5HSDLU
7URXEOHVKRRWLQJ
>2SULFDO(QJLQH@%URNHQ
>0$%RDUG@%URNHQ
2SWLFDO
(QJLQH
$63
0$
%RDUG
$63
$63
$63
5HSODFH
'5GDWD
2SWLFDO
(QJLQH
2SWLFDO
(QJLQH
0$
%RDUG
0$
%RDUG
2SWLFDO
(QJLQH
0$
%RDUG
2SWLFDO
(QJLQH
0$
%RDUG
2SWLFDO
(QJLQH
0$
%RDUG
Check in advance (P.154)

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
