Epson EB-W06 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 145 Revision A
3.5.2 Initialization
After repairing this product, carry out the following initialization check. When repairing a Safety Device, refer to " 3.5.1 Safety Check after Servicing (p142)" and
carry out the necessary procedure for safety.
3.5.3 Operation Check for control panel
After replacing/removing the control panel, carry out the check below following the instructions. (See " Troubleshooting on Operation Abnormality (p49)")
3.5.4 Operation Check for remote controller
After repairing the remote controller, carry out the check below following the instructions. (See " Troubleshooting on Operation Abnormality (p49)")
Procedure Check items
1. Connect the power cable.
Does the [Power] LED light blue?
2. Press the [Power] button on the projector to turn it on.
Does the [Power] LED flash blue, then light blue?
Does the lamp light?
Procedure Check items
1. Press the [Power] button on the projector to turn it on.
2. Check each button on the control panel if it works properly.
Does the [Power] button switch on/off the projector?
Does the [Source Search] button switch the sources?
Does the [Home] button display/close the home screen?
Does the [Menu] button display/close the menu?
Is the screen corrected to the standard with the [H/V] button?
Does the [Esc] button stop the current function?
Procedure Check items
Press the [Power] button on the remote controller to turn the projector on. Does the [Power] button on the controller switch on/off the projector?

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
