Epson EB-W06 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 153 Revision A
3.6.2 Preparation
Obtain the following tools from the Tech Exchange in advance.
Note *1:(Definition file)
*2:Use the latest ones referring to "TI18-25E".
3.6.3 Operating Procedure
3.6.3.1 Workflow
The whole replacing operation work flow is shown below.
Workflow for the replacement using DR data
Tool Name Remark
CAT (IRIS/CAT)*
1
Install it in your PC.
"IRIS_MENT.zip" file*
2
Save this file to the specified folder.
Model Group List*
2
Necessary for selecting the current
model on the CAT, and also for
preparing the correct ASP for the
projector to be repaired.
In the following procedure, refer to the "CAT Operation
Manual" published as the technical information "AP08-
0912E" for more detailed operation procedures of CAT.
Check in advance (P.154)
Replacing the Optical Engine (P.156)
Replacing the MA Board (P.158)

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
