EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 149 Revision A
MA Board Possible
Before
Read out the lamp operation time from the old MA Board. (IPS Tool)
" 3.5.10 Service tool list (p150)"
Back up the DR data of Optical Engine from the old MA Board. (CAT)
" 3.6 Writing the DR Data (p152)"
After
*1 Write the current firmware
by "USB for Updater" or "EasyMP Network for Updater" or (IPS Tool/IDOL).
" 3.5.10 Service tool list (p150)"
Set the destination. (RESCUE)
" 3.5.10 Service tool list (p150)"
Write the DR data of Optical Engine to the new MA Board. (CAT)
" 3.6 Writing the DR Data (p152)"
Calibrate G-sensor.**
" 3.7 G Sensor Calibration (p161)"
*2: Calibrate on for (Screen Fit/Frame Fit/Easy setup).** Non-applied for this model.
Set the commander and receiver for stack 3D display.** Non-applied for this model.
Set the "local time".**
" 3.3.9 RTC Board (p97)"
Write the lamp operation time to the new MA Board. (IPS Tool)
" 3.5.10 Service tool list (p150)"
Perform the Panel Alignment. **
" 3.8 LCD Alignment (p162)"
MA Board Impossible
Before Take the DR data from the "Intramart" data base. (Intramart)
" 3.5.10 Service tool list (p150)"
After
*1 Write the current firmware
by "USB for Updater" or "EasyMP Network for Updater" or (IPS Tool/IDOL).
" 3.5.10 Service tool list (p150)"
Set the destination. (RESCUE)
" 3.5.10 Service tool list (p150)"
Write the DR data of Optical Engine to the new MA Board. (CAT)
" 3.6 Writing the DR Data (p152)"
Calibrate G-sensor.**
" 3.7 G Sensor Calibration (p161)"
*2: Calibrate on for (Screen Fit/Frame Fit/Easy setup).** Non-applied for this model.
Set the commander and receiver for stack 3D display.** Non-applied for this model.
Set the "local time".**
" 3.3.9 RTC Board (p97)"
Perform the Panel Alignment. **
" 3.8 LCD Alignment (p162)"
Replaced part name
Power on
was possible/
impossible
Before/after
replacement
Required adjustment tasks (service tools name) Reference for the tasks
