Epson EB-W06 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 15 Revision A
I/O
Video input
Analog
D-sub 15pin 2 (Blue molding)
RCA 1 (Yellow)
DigitalHDMI1122222
Video output Analog D-sub 15pin 1
Audio
Input
RCA (L/R) 1
Stereo mini 2
OutputStereo mini1111112
Mic Input Stereo mini — — — 1 1 1 1
I/O
USB
Type A —111111
Type B 1
RS232C D-sub 9pin 1 (for servicing only)
Network
Cable LANRJ45 —111111
Wireless LAN
USB TypeA
(ELPAP11)
— 1 1 Optional Optional Optional 1
I/O
Wireless
connection
Screen Mirroring —
Operating Temperature
Temperature
5°C to 40°C [41°F to 104°F] (Elevation 0 to 2,286 m)
5°C to 35°C [41°F to 95°F] (Elevation 2,287 m or more)
Humidity 20% - 80% humidity
Operating Altitude
Normal 0 m to 3,048 m <0 ft to 10000 ft>
High altitude mode 1500 m <4921 ft> or more
Start-up period Less than 6 seconds
Warm-up period 30 seconds
Cool-down period Instant off
Power on was possible/impossible 100 - 240 V AC +/- 10%, 50/60 Hz
Model
EB-E20 EB-X49 EB-W49 EB-972 EB-982W EB-118 PL 119W
Item

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
