Epson EB-W06 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 168 Revision A
M-CUSHION H1W3L29 M-CUSHION,SHIELD;H1W3L29;PH
M-CUSHION H1W3L39 M-CUSHION,SHIELD;H1W3L39;PH
M-CUSHION H1W3L54 M-CUSHION,SHIELD;H1W3L54;PH
M-CUSHION H1W4L19 M-CUSHION,SHIELD;H1W4L19
M-CUSHION H1W10L17 M-CUSHION,SHIELD;H1W10L17;PH
WFD Shield Plate SHIELD PLATE,WFD;K;PH
FFC 30P FFC,SHIELD,30P-H838
FFC WFD-MA FFC,WFD-MA;22;H824
FFC WFD-WRF FFC,SHIELD,WFD-WRF;20;H814
WRF Holder HOLDER,WRF;K;PH
P3dash Module P3dash module
Upper Case
CASE,UPPER;H971-WH;PH
CASE,UPPER;KB-WH-J;PH
CASE,UPPER;KB-WH-E;PH
CASE,UPPER;KAL-WH-E;PH
CASE,UPPER;KAH-WH-E4;PH
CASE,UPPER;KAH-WH-E3;PH
CASE,UPPER;V-WH-E;PH
CASE,UPPER;V-WH-J;PH
CASE,UPPER;KAH-WH-E;PH
CASE,UPPER;KAH-BK-E;PH
CASE,UPPER;H978-WH-J;PH
CASE,UPPER;H978-WH;PH
CASE,UPPER;V-BK-E4;PH
CASE,UPPER;V-WH-J1;PH
CASE,UPPER;V-WH-E1;PH
CASE,UPPER;KAH-WH-E1;PH
Upper Cushion A
CUSHION,UPPER;A
CUSHION,PROLENS,A
Upper Cushion A-H722 CUSHION,UPPER;A-H722;PH
Name used in this manual SPI Parts Name
Upper Cushion B
CUSHION,UPPER;B,PH
CUSHION CASE UPPER;A
CUSHION,UPPER;B,PH
Sheet Upper A SHEET,UPPER;A-H850;PH
Sheet Lid Lamp SHEET,LID LAMP;H850;PH
Sheet Upper H854 SHEET,UPPER;H854;PH
Upper Case
COVER,CASE UPPER;PH
COVER,CASE UPPER;V;PH;2
Lid Lamp Switch SWITCH,LID LAMP;PH;2
H Key Assy H KEY ASSY;H972;PH;AS
LED Lens LENS,LED;A;PH
SW Button
BUTTON,SW;H971;PH
BUTTON,SW;a-WH;PH
BUTTON,SW;a-BK;PH
Power Button
BUTTON,POWER;AW
BUTTON,POWER;AB
SW Cable CABLE,SW; Au;PH;2
SW Board
PCB ASSY;H971SW-MP;PH
PCB ASSY;H981SW-MP;PH
PCB ASSY;H972SW-MP;PH
PCB ASSY;H980SW-MP;PH
Front Case
CASE UNIT,FRONT;H976;PH
CASE,FRONT;KH1a-WH;PH
CASE UNIT,FRONT;H974-WH;PH
CASE UNIT,FRONT;H974-SV;PH
CASE UNIT,FRONT;H978a;PH
CASE UNIT,FRONT;H980;PH
Shutter frame
FRAME,SHUTTER;KL;PH
FRAME,SHUTTER;KH;PH
FRAME,SHUTTER;V;PH
FRAME,SHUTTER;KH1;PH
Switch Cable H721-A CABLE,SWITCH-H721-A;PH;2
Name used in this manual SPI Parts Name

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
