EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 17 Revision A
 EB-FH06/FH52/992F, EH-TW740/TW750
Model
EB-FH06 EB-FH52 EB-992F EH-TW740 EH-TW750
Item
Specific
ation
of main
part
LCD
Size 0.61 inch (C2fine)
Pixel number 2,073,600 pixels (1920 x 1080) x 3
Native resolution Full HD
Aspect ratio 16:9
Projection Lens
Focus Type Manual
Zoom
Type Manual Manual Manual Digital Manual
Ratio 1-1.2 1-1.6 1-1.6 1-1.35 1-1.2
Lamp
Type UHE
Power consumption 210W 230W 230W 210W 210W
Life
Normal 6,000 hours 5,500 hours 6,500 hours 6,000 hours 6,000 hours
Medium — — 10,000 hours — —
Eco 12,000 hours 12,000 hours 17,000 hours 12,000 hours 12,000 hours
Brightn
ess
Normal mode
Color mode: Dynamic,
Zoom: Wide
3,500lm 4,000lm 4,000lm 3,300lm 3,400lm
Medium mode — — 3,400lm — —
Eco mode 2,300lm 2,400lm 2,400lm 2,200lm 2,200lm
Sound output Monaural: 2W x 1
Monaural: 16W x 1 Monaural: 16W x 1 Monaural: 2W x 1 Monaural: 2W x 1
I/O
Video input
Analog
D-sub 15pin 1 (Blue molding) 1 (Blue molding) 2 (Blue molding) — 1 (Blue molding)
RCA 1 (Yellow) 1 (Yellow) 1 (Yellow) — 1 (Yellow)
DigitalHDMI2 2212
Video output Analog D-sub 15pin — — 1 — —
Audio
Input
RCA (L/R)111—1
Stereo mini — — 2 — —
Output Stereo mini — — 1 1 1
Mic Input Stereo mini — — 1 — —

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
