Epson EB-W06 Service Manual

EB-E01 series Appendix INTERNAL USE ONLY
SEIKO EPSON 180 Revision A
 Device ID name (sensor error)
04 PBS
05 EX
06 PBS2
07 EX1
10 POWER
11 LV2
12 LV3
13 LUMI
14 PS
15 PB
16 LMP2
17 PS2
18 EX2
19 PEL
1A LMP3
1B PUMP
1C PEL1
1D PEL2
1E YLD
1F PHW
22 LD1
23 LD2
24 BDM
25 ROUT1
26 ROUT2
27 RIN1
28 RIN2
29 LVR
2A LVG
2B LVB
2C LSM
ID Display
2D EX3
2E PWIN
2F PWOUT
30 LDDR
31 PEL3
32 PEL4
ID Display
00 LV
01 LMP
02 LMA
03 PBS
04 AMIBENT
05 PWR
06 WIND
07 IRIS
08 SCI
09 AIR
0A PB
0B LWR
0C PS2
0D WIHD
0E IM
0F LV2
10 EX
11 YLD
12 PHW
13 BLD
14 YDR
15 BDR
ID Display

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
