Epson EB-W06 Service Manual

EB-E01 series Appendix INTERNAL USE ONLY
SEIKO EPSON 182 Revision A
 Device ID name (laser error, warning)  Device ID name (internal error)
 Source name
ID Display
01 Ary1
02 Ary2
03 Ary3
04 Ary4
05 Ary5
06 Ary6
0B Drv1
0C Drv2
0D Drv3
0E Drv4
0F Drv5
10 Drv6
15 Drv Com
16 Motor
17 Motor Com
1B Ary1
1C Ary1
1D Ary2
1E Ary2
1F Ary3
20 Ary3
25 Drv1
26 Drv2
27 Drv3
28 Drv4
29 Drv5
2A Drv6
2B Src
ID Display
00 CAMERA
Source Display
C-VIDEO Video
S-VIDEO S-Video
BNC BNC
DSUB Computer
DSUB2 Computer2
DVI DVI
HDMI HDMI
HDMI2 HDMI2
HDMI3 HDMI3
DisplayPort DisplayPort
SDI SDI
HDBaseT HDBaseT
WFD Screen Mirroring
USB USB
USB Display USB Display
LAN LAN
MessageBroadcast Message Broadcast
NW Menu Network Menu
Schedule Schedule Menu
WB Menu White Board Menu
USB USB
USB2 USB2
WhiteBoard WhiteBoard
MPP Participant list
RDP RDP

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
