Epson EB-W06 Service Manual

EB-E01 series Product Description INTERNAL USE ONLY
SEIKO EPSON 19 Revision A
Power
consum
ption
100-120V Area
(JAPAN, USA,
etc.)
Lamp
ON (Normal) 345W
ON (Medium) — — 303W — —
ON (Eco) 235W
Standby (Network On) 2.0W
Energy Saving 0.3W
220-240V Area
(Europe, etc.)
Lamp
ON (Normal) 327
ON (Medium) — — 290W — —
ON (Eco) 235W 225W 225W 225W 225W
Standby (Network On) 2.0W
Energy Saving 0.3W
Rated Voltage & Current (Except Japan) 100 - 240 V AC 50/60 Hz 3.5A - 1.6A
Size
Excluding feet
Unit: mm
302(W) x 87 (H) x
249 (D)
309(W) x 90 (H) x
282 (D)
309 (W) x 90 (H) x
282 (D)
302(W) x 87 (H) x
249 (D)
302(W) x 87 (H) x
249 (D)
Maximum Dimension
302(W) x 92 (H) x
252 (D)
309(W) x 105 (H)
x 293 (D)
309 (W) x 105 (H)
x 293 (D)
302(W) x 92 (H) x
252 (D)
302(W) x 92 (H) x
252 (D)
Weight
Approx. 5.95 lbs./
2.7 kg
Approx. 6.83 lbs./
3.1 kg
Approx. 6.83 lbs./
3.1 kg
Approx. 5.95 lbs./
2.7 kg
Approx. 6.17 lbs./
2.8 kg
Fan
noise
Normal mode 37 dB
Eco mode 28 dB
Model
EB-FH06 EB-FH52 EB-992F EH-TW740 EH-TW750
Item

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
