EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 95 Revision A
Fold the "FFC 30P" as shown in this figure.
Fold the "FFC WFD-MA" as shown in this figure.
Affix each "M-CUSHION" to the positions shown in the
figure.
M-CUSHION H1W4L19
M-CUSHION H1W3L39
M-CUSHION H1W3L29
M-CUSHION H1W3L54
