Front
A
Rear paper feeder Loads paper.
B
Paper support Supports loaded paper.
C
Feeder guard Prevents foreign substances from entering the printer. This cover should
usually be closed.
D
Edge guide Feeds the paper straight into the printer. Slide to the edges of the paper.
E
Disc/ID card tray slot Insert the disc/ID card tray into the top section of the output tray.
F
Output tray Holds the ejected paper. Pull out manually and push it back in to store.
G
Disc/ID card tray When printing on a disc or ID card, remove this tray from the bottom of the
printer, place a disc or ID card, and then insert it into the disc/ID card tray
slot. When not printing on a disc or ID card, store this tray in the bottom of
the printer without placing anything on it.
Part Names and Functions
>
Front
16
