18
INK (ink) LED: Red
•Flashes when the ink is low or waste ink in the ink cartridge is nearly full.
•Lights when it is time to replace the ink cartridge, when the ink cartridge is not installed or is
not correctly installed, and when waste ink in the ink cartridge is full.
•Lights off when ink in the ink cartridge is adequate.
PAPER (paper out) LED: Red
•Lights when the paper is not installed or is not correctly installed.
•Lights off when the paper is correctly installed.
Connectors
All cables are connected to the connector on the lower rear of the printer.
•Power supply connector: Connects cable of the AC adapter. The AC adapter itself is installed
at factory before shipping.
•USB Connector: Connects the printer with the host computer via interface.
•Inlet (AC Adapter): Connects the AC cable.
Paper ejection tray
Installing the paper ejection tray enables you to accumulate printed paper temporarily in it.
• The INK LED does not flash even if the ink is low when the “LED Notification Setting at
Ink Low” is set not to appear on [Notification Settings] on [Maintenance And Utilities] tab
of the printer driver.
• The printer status is also displayed with combination of lighting and flashing of LED’s.
See "Status/Error Indications" on page 19 for details.
For details how to connect the interface and power supply connector, see "Connecting the
Printer to the Host Computer" on page 68.
• For how to attach the paper ejection tray, see "Attaching/Adjusting the Paper Ejection
Tray" on page 99.
• For maximum capacity for ejected paper of the paper ejection tray, see "Paper Ejection
Tray" on page 53.
Paper may fall from the paper ejection tray due to a curl or the length of the paper.
