Nozzle Check
The pattern is printed to check the nozzle status and evaluate the pattern for clogging.
Follow the steps below to check nozzles.
1
Turn the power on.
2
Set the die-cut label, receipt or continuous label which length is 90 mm
or more.
3
Display the window on the printer driver. (See "How to Use the Printer
Driver" on page 160 for how to display the driver window.)
4
Click [Media position detection] on [Maintenance And Utilities] tab and
sets the media position detection based on the loaded paper.
5
Click [Nozzle Check].
6
Click [Print].
7
Check the printed nozzle pattern.
Execute Manual Head Cleaning when it is clogged.
