Chapter 1 Product Overview

External Dimensions

•Height:261 mm

•Width: 255 mm

•Depth: 275 mm

[Unit: mm]

300

255

261

300

275

457 (when the paper ejection tray is extended)

388 (when the paper ejection tray is shortend)
