184
Specifying the 2D symbol data
See the following description to specify the 2D symbol data.
PDF417
❏ Calculated automatically when the digit number and the line number are 0.
❏ To specify other number than 0, make sure the multiplication of the digit number and the line
number is under 928.
QRCode
❏ Size is determined by the specified version. If it does not fit in the specified version, it is
changed automatically to the appropriate version.
MaxiCode
❏ For Mode2 and Mode3, the header and the second message are omissible.
❏ Specify the special character as the following format.
GS1 DataBar Stacked /GS1 DataBar Stacked Omnidirectional
❏ Up to 13 digits of data can be specified.
❏ Do not specify the application identifier ‘01’ for the head of the data.
❏ A check digit need not to be attached to the data.
GS1 DataBar Expanded Stacked
❏ Multiple line symbol version of GS1 Databar Expanded. How to specify the data is the same as
GS1 Databar Expanded. (For details, see "GS1 DataBar Expanded" on page 177.)
For the composite symbol and the HRI character, see "Specifying the barcode data" on
page 170.
Control Character Hexadecimal
SHIFT 0x7B, 0x53
CODE B 0x7B, 0x42
CODE C 0x7B, 0x43
FNC1 0x7B, 0x31
FNC2 0x7B, 0x32
FNC3 0x7B, 0x33
FNC4 0x7B, 0x34
