28
Printing Specifications
dpi: dots per inch
*1: When printing with the default print density level at 24V and 25°C {77°F}.
Character Specifications
Note:
1. Space between characters is not included.
2. Characters can be scaled up to 64 times as large as the standard size.
80 mm width paper printing 58 mm width paper printing
Printing method Thermal line printing
Dot density 180 × 180 dpi
Printing direction Unidirectional with friction feed (Reverse feed is not
supported.)
Printing width 72.0 mm (2.83"), 512 dots 50.8 mm (2.0"), 360 dots
Characters per line Font A (12 × 24) 42 30
Font B (9 × 17) 56 40
Maximum print speed*
1
300 mm/s
Line spacing 4.23 mm {1/6"} (Initial setting)
Number of characters Alphanumeric characters: 95
Extended graphics: 128 × 43 pages (including user-defined page)
International characters: 18 sets
Character structure Font A (default): 12 × 24 (including 2-dot horizontal spacing)
Font B: 9 × 17 (including 2-dot horizontal spacing)
Character size Font A Standard: 1.41 × 3.39 mm
Double-height: 1.41 × 6.77 mm
Double-width: 2.82 × 3.39 mm
Double-width, double-height: 2.82 × 6.77 mm
Font B Standard: 0.99 × 2.40 mm
Double-height: 0.99 × 4.80 mm
Double-width: 1.98 × 2.40 mm
Double-width, double-height: 1.98 × 4.80 mm
To Next Page
