Chapter 1 Product Overview
35
1
External Dimensions and Mass
•W
i
d
t
h: Approx
i
ma
t
ely 14
5 mm {5.71"}
•D
e
p
t
h: Approx
i
ma
t
ely 195 mm {7.68"}
•H
e
ig
h
t
: Approx
i
ma
t
ely 148 mm {5.83"}
•
Mass: Approx
i
ma
t
ely 1.6 k
g
{3.53 lb} (excep
t
for r
oll paper)
[Units: mm]
