Chapter 2 Setup
43
2
Setting the DIP Switches
On this printer, you can make various settings with DIP switches.
Change the setting if necessary.
Setting Procedure
Follow the steps below to change the DIP switch settings.
1
Make sure the power supply for the printer is turned off.
2
Unscrew the screw to remove the DIP switch cover from the base of the
printer.
3
Set the DIP switches, using the tip of a tool, such as a small screwdriver.
4
Replace the DIP switch cover, and screw it in place.
CAUTION
Before you remove the DIP switch cover, turn the printer off.
Otherwise, a short-circuit may cause the printer to malfunction.
DIP switch settings are enabled only when the power is turned on or the printer is reset via
the interface. If the settings are changed after that, the functions will not change.
DIP switch bank 1
DIP switch bank 2
To Next Page
