58
Connecting the Optional External Buzzer
When using the optional external buzzer (OT-BZ20), install the optional external buzzer.
You can use the optional external buzzer (OT-BZ20) by connecting it to the drawer kick-out
connector.
Check whether the following items are included. If any item is damaged, contact your dealer.
Installation Position
This product is recommended to be installed on either side of the printer.
The optional external buzzer and the drawer cannot be used together at the same time.
If you configure the memory switch (customized value) setting to enable the optional
external buzzer, the drawer cannot be opened because the pulse is not sent to the
drawer kick out connector pin.
Make sure to use the accessory affixing tape (hook and loop fastener) to attach the
optional external buzzer to the printer.
Be careful not to spill water, oil, solvent, or any other liquid over the printer. Doing so may
result in malfunction of the printer.
Do not install the optional external buzzer at the roll paper exit.
To prevent liquid from entering inside, it is recommended to install the optional external
buzzer so that the volume adjustment knob is positioned sideways or downward. (For
details of the volume adjustment knob, see "Adjusting the Buzzer Volume" on page 60.)
Optional external buzzer
Affixing tape
(1 pair, 2 pieces)
User’s Manual
To Next Page
