44
Functions
DIP Switch Bank 1
DIP Switch Bank 2
SW Function ON OFF
Initial
setting
1-1 Auto line feed Always enabled Always disabled OFF
1-2 Receive buffer capacity 45 bytes 4 KB OFF
1-3
Selects paper sensors to output
paper-end signals (initial
setting)
Disabled
Roll paper end sensor
enabled, roll paper
near-end sensor
enabled
OFF
1-4 Error signal output Disabled Enabled OFF
1-5
1-8
Undefined — OFF
SW Function ON OFF
Initial
setting
2-1
Reserved (Do not change
setting)
Fixed to ON ON
2-2
Reserved (Do not change
setting)
Fixed to OFF OFF
2-3
2-4
Selects print density
See "Selecting the Print Density (DIP Switches
2-3/2-4)" on page 45.
OFF
2-5
Sets the release condition of the
receive buffer BUSY state. (This
function is effective when DIP
Switch 1-2 is set to off.)
Releases the BUSY
state when the
remaining capacity
of the receive buffer
reaches 138 bytes.
Releases the BUSY
state when the
remaining capacity
of the receive buffer
reaches 256 bytes.
OFF
2-6
2-7
Reserved (Do not change
settings)
Fixed to OFF OFF
2-8
IF pin 31 reset signal (Do not
change setting)
Fixed to ON ON
Do not change the setting of DIP switches 2-1, 2-2, 2-6, 2-7, and 2-8. Otherwise, the printer
may not operate normally.
