30
58 mm paper width printing
The printable area of paper with a width of 57.5 ± 0.5 mm {2.26 ± 0.02"} is 50.8 ± 0.2 mm {2.00 ±
0.008"} (360 dots), and the space on the left side is approximately 3.7 mm {0.15"} and the space on
the right side is approximately 3.0 mm {0.12"}.
In 2-divided energizing, the print position within the printable area of the thermal
elements for dots 1 to 256 and 257 to 360 is shifted approximately 0.07 mm {0.0028"} in
the paper feed direction as shown in the figure below.
In 4-divided energizing, the print position within the printable area of the thermal
elements for dots 1 to 128, 129 to 256, and 257 to 360 is shifted approximately 0.04 mm
{0.0016"} in the paper feed direction as shown in the figure below.
0.141 0.05 mm {0.0056 0.002”}
57.5 0.5 mm {2.26 0.02”}
+
-
+
-
50.8 0.2 mm {2.00 0.008}
+
-
+
-
3.7 mm {0.15} 3.0 mm {0.12}
+
-
+
-
All the numeric values are typical.
2561
257
360
About 0.07 mm
