52
Connecting the Ethernet interface cable
Connect a 10BASE-T/100BASE-TX cable to the 10BASE-T/100BASE-TX LAN connector by
pressing firmly until the connector clicks into place.
CAUTION
When LAN cables are installed outdoors, make sure devices without proper surge
protection are cushioned by being connected through devices that do have surge
protection.
Otherwise, the devices can be damaged by lightning.
Never attempt to connect the customer display cable, drawer kick-out cable, or a
standard telephone line cable to the 10BASE-T/100BASE-TX LAN connector.
