Escea DX1000 - S10 Wiring Diagram

B
A C D E F G SERVICE
56
S10 Wiring Diagram
CON6
CON10
CON9
TRANSFORMER 240VAC - 18VAC
ISOLATING
VALVE & PILOT
MAIN BURNER
WIFI
MODULE
FLAME SAFETY CONTROLLER
FENWAL 35-61
i
-
con
OPTIONALWIRELESS NETWORK
Part No. 620278
W
V2
L1
R
IND
PSW
V1
GND
S1
SPARK
ELECTRODE
ESCEA
CONTROLLER
MAINS FUSE (2A)
NETWORK
(RJ45)
NETWORK CABLE
FLUE FAN
FUSE (1.5A)
ROOM FAN
FLUE FAN
MAIN BURNER
FLOW CONTROL
i
A
N N
N
E
Main Tray/Chassis
Connector (CN1)
Controller and Valve
Tray Schematic
