B
A C D E F G SERVICE
32
E8 Remove the Fuelbed Tray & Burners
Remove the fuelbed tray from the fire box, by lifting one end up into the top corner and then
out towards you. Take care not to scratch the firebox paint and lift out the burners.
E9 Gas Type Conversion
THIS APPLIANCE IS CONFIGURED TO OPERATE ON NG.
If gas type conversion is not required then jump to ““E10 Checking the Gas Operating
Pressure” on page 34”.
NOTE: Access to the valve and control system can be through either of the 2 hatch panels shown
shaded black in the diagram of section E10 on page 34.
Your gas fire has been supplied with the necessary parts for gas conversion. Follow the steps on
the following page to change from NG to ULPG/Propane or vice versa.
WARNING: The regulator that is supplied with the fire MUST NOT BE REMOVED.
Removal of the regulator, or replacing it with one not intended for use with this Escea fire, will
void the limited appliance warranty.
Turn o power and gas first.
Step 1: Ensure the power and gas are o. Remove the fascia, glass, and fuelbed as per
section E7 on page 31.
Step 2: Lift out the two burners and the surrounding perforated grill as per section E8 on page
32.
Step 3: Remove the screws in the bottom and the inner side of the firebox as per shown.
To Next Page
