IP Server 900 Programming Manual Function 2: CO line programming
E.9
1. Choose CO lines to program
You can select from the first set of 12 CO lines on the first T1/PRI Module. Use the scroll keys to view
the next 12 CO lines on the same T1/PRI Module. To see the first 12 CO lines on the second T1/PRI
Module (if installed), scroll again; if there is only one T1/PRI Module installed, scrolling will return you to
the first 12 CO lines.
Note: A 48-Key Feature Phone will display the first set of 24 CO lines on the T1/PRI Module; scrolling
again will allow you to select the 24 CO lines on a second T1/PRI Module.
Select the COs to program alike and press # to confirm. The LED will glow green and then, after a CO
is programmed, the LED will glow amber. The programming of the first CO should default forward for
the remaining COs selected. After the selected COs are programmed, the LED will glow amber.
For example: if a T1/PRI Module is on the second carrier card, the display will be:
CC 3 T1 DAY
28-51 >
Note: Only one T1/PRI Module is allowed per carrier card, with no more than two T1/PRI Modules in
the system.
2. Select trunk type emulation
Use the scroll keys to select the trunk type emulation: either E&M DNIS/DID, E&M, LOOP START or
GROUND START. Press # to confirm. (Default is E&M DNIS/DID.)
TRUNK EMULATION
E&M DNIS/DID >
If you select LOOP START or GROUND START, continue with the outbound CO line groups and
answer ring assignment.
If you select E&M DNIS/DID, the lines are routed to the DNIS/DID table.
1
After the E&M programming is
complete, name the CO lines and then select the outbound CO line groups.
If you select E&M, the lines are routed to the answer ring assignment. After the E&M programming is
complete, name the CO lines and then select the outbound CO line groups and the answer ring assignment.
To complete the programming of the E&M trunks selected:
1. Use the scroll keys to select the outgoing signal type — WINK START, IMMEDIATE START
or DIAL TONE START. Press # to confirm.
Default: WINK START.
OUTGOING SIGNAL
DIAL TONE START>
2. Use the scroll keys to select the incoming signal type — either WINK START or
IMMEDIATE START. Press # to confirm.
Default: WINK START.
INCOMING SIGNAL
IMMEDIATE START>
(Continued)
1
Also if E&M DNIS/DID is selected: Caller ID over T1 is not supported.
