IP Server 900 Programming Manual Function 2: CO line programming
E.16
Function 214: SIP trunk programming
For SIP trunk programming, press 1 to go to Function 2141. To create a SIP account, press 2 to go to
Function 2142. For DID enable/disable, press 5 to go to Function 2145.
Important: Perform SIP trunk programming in this order: Function 2142 (page E.18), then Function 2141 (starting
below), then Function 2145 (page E.24). For more details, refer to the ESI SIP Trunking Installation
Guide (ESI # 0450-1227).
Function 2141: SIP trunk programming
Steps 1–7 affect SIP trunk programming for day mode, while steps 8–13 affect SIP trunk programming for
night mode.
1. Select the line keys that are to have the same programming during day mode, and press # to confirm.
For this example, we’ll be using the IP/ASC Carrier Card in position 1 (“CC 1”). Below, XX–XX
represents the SIP ports as they are installed in the system.
CC 1 SIP DAY
52-59 >
Notes: You will be able to select only the number of CO lines for which you have licenses.
Only carrier card 1 supports SIP trunk programming.
2. Use the scroll keys to select the SIP provider to be used for the selected trunks, and press # to confirm.
For this example, we’ll be using SIP provider 1.
Range: 1–10 (as previously defined in Function 2142; for instructions on programming that function, see
page E.18).
SEL PROVIDER #
1-BROADVOX
3. Enter the line name (if you want to use a different one than what appears), and press # to confirm.
If you need detailed information about entering characters, press HELP.
Range: Up to 10 characters. Default: [Blank].
CO LINE
NAME:
4. If tenant service is enabled in Function 169 (page D.11), use the scroll keys to select the tenant
number, and press # to confirm. (If tenant service isn’t enabled, press # to move to the next step.)
Range: [Any valid tenant number]. Default: 1.
CO LINE
TENANT: 1
5. This line is programmed for the line groups as displayed. Enter the new group number (if there is one),
and press # to confirm.
Range: 9, 8, 71–76 (if 71–76 were assigned as CO lines, in Function 164 [page D.7]). Default: 9.
DAY CO LINE
CO GROUP: 9
(Continued)
