IP Server 900 Programming Manual Function 3: Station programming
F.21
8. CO line group — Assign the extension’s ability to access one or more CO line groups
(9, 8, and 71–76).
Default: 9.
9. and 10. Call forward busy/no answer — The extension can be set to call forward busy/no
answer to another extension (or department), a mailbox or a branch ID for day mode and
differently for night mode.
Default: The extension’s mailbox.
Troubleshooting IP phone setup mode programming
Note: The displays shown appear on an ESI desktop IP phone.
What’s displayed on the IP phone What it means • Possible remedies
ALREADY ASSIGNED
RE-ENTER TO REPLACE
The extension number you entered is already assigned.
Enter a different extension number or press RELEASE to exit
setup mode.
COM LINK LOST...
RECONNECTING
The phone is attempting to reconnect to the system.
If this message doesn’t clear within 10–15 seconds, check
programming, cable connections, and network equipment.
ESI IP FP2 V1.9
MAC:00304D000000
↑EP CRC:7458
The phone is powered-up but can’t reach the system.
Check programming, cable connections, and network equipment.
ENTER PASSWORD
PASSWORD WAS INVALID
You entered an invalid Installer password.
Enter the correct Installer password.
ENTER EXTENSION
EXTENSION WAS INVALID
You entered an extension number that either isn’t on the system or isn’t
within the extension number range selected in Function 169.
Enter a correct extension number.
ENTER EXTENSION
NO LICENSE WAS AVAILABLE
There are no available licenses for this extension.
You can obtain additional ESI IP station licenses by contacting your ESI
sales representative at 800 374-0422 or use Function 31 to delete the
MAC addresses of any unused IP extensions.
To Next Page
