ES415.1 - User’s Guide48
Getting Started ETAS
6. Fasten the screw with the module from the right
side of the ES4xx angle bracket.
Both parts are now completely connected mechan-
ically.
Connecting with Additional Modules
Several ES400 modules can be fastened to the other component with the con-
nection type described in this chapter if you connect all modules to be attached
first with each other step by step (see chapter 5.2.2 on page 37). The module
which is the furthest to the right of the module block is subsequently connected
with the ES4xx angle bracket (right) as a single module and fastened to the DIN
rail using screws.
Connecting the ES4xx Angle Bracket with the DIN Rail
Connecting the ES4xx Angle Bracket (right) with the DIN rail
1. Place the ES4xx angle bracket onto the DIN rail.
2. Insert the hooks of the ES4xx angle bracket into the
upper part of the DIN rail.
3. Engage the ES4xx angle bracket in the DIN rail by
pressing on the ES4xx angle bracket or the module.
The module connected with the ES4xx angle
bracket is fastened to the DIN rail.
Screw the two parts together without canting the
threads!
If a module is screwed onto the other component, no additional modules can
be screwed onto this module-component connection.
