1 General Information 13
Crossfader
The Crossfader consists of a Live and Next fader, plus the Crossfade transport buttons. It
can be used for fading between the 199 steps of the programmable Stack, or for single-
scene fading into intensities that are set blind in NEXT mode. Stack & Crossfader, page 87
The following buttons are used together with the crossfader
Sequence & Stack Functions
These buttons are used to program and edit Sequences in the Mems faders, and the Stack
of the Crossfader. See “Sequences” on page 58. See “Stack” on page 60.
Record & Edit Functions
The row of buttons over the legend RECORD offer recording and editing functions
described in the Program and Edit chapters of this manual.See “Program” on page 39.
See “Edit” on page 65.
The Select Section
This section of 24 buttons is used to select devices, groups, palettes and effects. It uses
the buttons in the Attributes, Selection and Modify sections to do this. See “Devices” on
page 42.
Attributes functions
These buttons are used to select modes for the 24 select buttons above them, and for
masking and programming. See “Device Parameters” on page 45.
.....
Selection functions
These buttons are used to select and work with Devices in the 24 select buttons above
them. See “Devices” on page 42.
Modify functions
These buttons are used to select and work with Effects in the 24 select buttons above them.
See “Effects” on page 51.
