44 SmartFade ML v3.0.1 User Manual
Device Groups
A quick way to recall a selection of devices is to store it as a group. There are 24 groups.
Record groups
Recall recorded groups
Action Console Feedback
1. Select devices ... Selected device buttons are lit to full (Device
Select mode has to be active).
2. Activate recording All buttons that can record in this mode will
blink (press CLEAR to exit).
3. Select groups GROUP lights up. All 24 select buttons will
blink at full. Already recorded ones will blink
dimmed.
4. Record group ... As soon as a select button is pressed, the
group is stored to that button. The console will
automatically return to Device Select mode.
Action Console Feedback
1. Activate groups GROUP lights up. All select buttons with a
recorded group light up at full in green.
2. Select group ... As soon as a select button is pressed, the
group is selected. The console will automati-
cally return to Device Select mode.
